Insulation Resistance Tester, Pumping Unit Multimeter Oilfield Field Tester Pumping Unit Tester ES9050

-The pumping unit multimeter uses the latest materials to design and manufacture the shell mold, equipped with a shock-proof, non-slip, high-insulation sheath, and adopts an LCD display. All the measured parameters are displayed on the same screen, which is clear at a glance, showing a beautiful and luxurious appearance.-The instrument is equipped with a DC charging interface and a USB interface, which can store 500 sets of data, and upload the stored data to the computer through the system software, which is convenient for leaders to query, and realize historical data query, reading, analysis, storage, reporting, printing, etc. At the same time, the meter also has the function of administrator setting, password entry, including clock setting, hash number setting, and password setting.Specification:Function: Simultaneously measure the electric parameters of the oil field: AC current, voltage, frequency, phase between voltage and current, on-off resistance value, maximum current of the pumping unit up and down stroke, stroke ratio, up and down stroke time, number of strokes per minutePower source: DC7.2V (1.2V 6 AA rechargeable batteries)Jaw size: round mouth current clamp: 34mm×36mmMeasuring range: (full automatic) Voltage: AC 0V～700V Voltage: AC 1V Voltage: ±(2%FS)Current: AC 0.0A～300A Current: AC 0.1A Current: ±(2%FS)Phase: 0°～360° Phase: 1° Phase: ±10°Frequency: 45.0Hz～65.0Hz Frequency: 0.1Hz Frequency: ±1 HzNumber of hash marks: 100Data storage: 500 groupsUSB interface: USB interface, upload the stored data to the computer, easy to analyze and manage the data, edit the hash number through the softwareCommunication line: USB communication line, 1 meter longPound sign setting: 11-digit code, the pound sign can be edited through the instrument or PC softwareClock function: YesPassword setting: Yes, 6-digit passwordBacklight function: Yes, suitable for dim places and night useAutomatic shutdown: the instrument will shut down after about 15 minutes of inactivityPower consumption: the maximum power consumption of the backlight is 50mA when the backlight is turned on, and the power consumption of the instrument is 30mA when the backlight is turned offDisplay mode: LCD display, 128dots×64dotsInstrument size: length, width and thickness: 204mm×100mm×35mmDetection rate: about 2 seconds/timeBattery voltage: The meter displays the battery voltage in a timely manner. When the battery voltage is lower than 5.5V, the battery voltage is low symbol is displayed, please charge it in timeMeter quality: about 1kg (including accessories)Length of test line: 1.5mCurrent clamp wire length: 2mWorking temperature and humidity: -20℃～40℃; below 80%RhStorage temperature and humidity: -10℃～60℃; below 70%RhInput impedance: Test voltage input impedance: 1MΩWithstand voltage: 1000V/50Hz sine wave AC voltage between the instrument circuit and the shell lasts for 1 minuteInsulation: ≥100MΩ between the instrument circuit and the sheath shellStructure: Double insulation, with insulating anti-vibration sheathSuitable for safety regulations: IEC61010-1 CAT Ⅲ 600V, IEC61010-031, IEC61326, pollution degree 2Package List:Host: 1PCInstrument package: 1PCCurrent clamp: 1PCSystem software CD: 1 PCUSB communication line: 1PCTest line: 2PCSCharger: 1PCRechargeable battery: 5 (1.2V AA battery) PCSManual, warranty card: 1 PC

• -The pumping unit multimeter is a fully automatic, multi-function, digital and intelligent instrument specially developed by our company for on-site testing of oil fields. It has the characteristics of high precision, high stability, low power consumption and convenient use.
• -It can measure the power parameters of the oil field at the same time: AC current, voltage, frequency, phase between voltage and current, the maximum current of the up and down stroke of the pumping unit, the stroke ratio, the up and down stroke time, the number of strokes per minute, so as to determine the pumping unit Working conditions
• -Provide a safe, accurate and convenient new type for electricity inspection personnel, oilfield pumping unit debuggers, engineering and technical personnel, electricians, oil production workers, and metering personnel to monitor the electrical parameters and electrical balance of pumping wells on site at any time Oilfield instrumentation.
