FTVOGUE R307 Optical Fingerprint Module Reader Sensor Access Control Attendance Recognition Device Module

Specification: Supply voltage: DC 4.2--6.0V Supply current: Working current: 50mA (typical) Peak current: 75mA Fingerprint image entry time: <0.1s Acquisition window area: 14*18 mm Matching method: Comparison method (1:1) Search method (1:N) Template file: 512 bytes Storage capacity: 1000 pieces Security level: 5 levels (low to high: 1, 2, 3, 4, 5) False acceptance rate (FAR): <0.0001% False Rejection Rate (FRR): <1.0% Search time: <0.2s Host computer interface: RS232 (TTL logic level), USB Communication baud rate: (9600xN)bps, N=1~12 (By default, N=6, baud rate = 57600bps) Working environment: -20~45℃, 10%-85% RH (no condensation) Storage environment: -40~55℃, <85% H (no condensation) Package List: 1 x R307 Optical Fingerprint Module 1 x Cable .

• The R307 Optical Fingerprint Module integrates fingerprint algorithm chip with functions such as fingerprint entry, image processing, feature extraction, template generation, template storage, fingerprint comparison (1:1) and fingerprint search (1:N).
• Fingerprint reader can conduct secondary development and can be embedded into various end products such as: access control, attendance, safety deposit box, car door locks.
• This product uses professional optical technology and module manufacturing process to make the product have low power consumption, low cost, small size and excellent performance.
• Good image processing capability, can successfully capture images up to 500 DPI resolution, making the machine more accurate in recognition
